Baofeng UV-5R EU Mini 1600 mAh Radio - Orange
- description
- technical data
- Reviews
- Goes well with
Baofeng UV-5R EU Mini 1600 mAh Radio - Orange
Baofeng UV-5R EU Mini is a handheld dual-band radio with a maximum output power of 5 W. It features a DTMF keypad, an LCD screen, a torch and an integrated FM radio. The device is powered by a lithium-ion battery with a capacity of 1600 mAh and a USB-C port.
Dual Watch Function, Bluetooth module, VOX function
The Baofeng UV-5R EU Mini includes the Dual Watch feature, allowing simultaneous monitoring of two channels. The user can communicate on the main frequency while listening to a secondary one. Switching between them is done using a dedicated button.
The device includes a colour display, a torch and an FM radio, enhancing its usability in the field. It also has a keypad lock to prevent accidental input.
The radio can be programmed using the keypad, a computer or a dedicated Bluetooth application. The built-in Bluetooth module allows wireless configuration from a smartphone, making operation quick and intuitive.
The VOX function enables voice-activated transmission without pressing the PTT button, which is convenient in situations requiring hands-free operation.
CTCSS and DCS tones
CTCSS and DCS tones operate in normal and invert modes. These systems filter out unwanted signals, receiving only transmissions with the correct tone or code, ensuring clear communication and reducing interference.
Set elements
- radio
- antenna
- 1600 mAh battery with USB-C port
- USB-C cable
- microphone-earpiece
- belt clip
- wrist strap
- user manual
Main features
- CTCSS and DCS operation
- maximum transmission power up to 5 W
- frequency 136-174 MHz
- FM radio 65-108 MHz
- 1600 mAh battery
- dual frequency monitoring (Dual Watch function)
- voice-activated transmission (VOX function)
- colour display
- built-in head torch
- Bluetooth module
| Maximum transmitting power | 5 W |
|---|---|
| VHF frequency range | 136-174 MHz |
| UHF frequency range | 400-480 MHz |
| Number of channels | 999 |
| Antenna | Unscrewable |
| Channel programming option | Yes |
| Channel scanning | Yes |
| PTT button | Yes |
| Dual Watch | Yes |
| VOX function | Yes |
| CTCSS/DCS (tone coding) | Yes |
| Flashlight | Yes |
| Power type | Interchangable accumulator |
| Display | LCD |
| Keyboard | Yes |
| PTT headset included in the set | Yes |
| FM radio | Yes |
| Body material | Synthetic |
| Accumulator/battery type | 1x Li-Ion |
| Dimensions | 108 x 52 x 37 mm |
| Additional accessories included | Yes |
| Charging port | USB-C |
| Weight | 200 g |
| Main color | Orange |
| EAN | 5901247920197 |
| Manufacturer code | UV-5R EU MINI Orange |
| Brand | BaoFeng |
