Pulsar Telos XL50 Thermal Imaging Monocular
or sign up for availability notification
- description
- technical data
- Reviews
- Goes well with
Pulsar Telos XL50 Thermal Imaging Monocular
A handheld thermal imaging monocular with a 50 mm objective diameter for easy observation both during the day and at night. The Telos XL50 features optical magnification from 2.5x to 20x. Thanks to the Zoom Boost function and 12x digital zoom, smooth magnification can be changed in the range from 2.5x to 30x, allowing observation of objects up to 2300 meters away. The durable and sealed construction ensures IPX7 water resistance.
Durable construction, IPX7 standard
The body of the thermal imaging monocular is made of plastic that is resistant to mechanical damage and shocks. Thanks to its compact design and the use of seals, the camera housing meets the IPX7 waterproof rating, which ensures protection against water at a depth of up to 1 m for 30 minutes. The operating temperature range of the thermal imaging monocular is from -25 to +50 degrees.
Amoled HD display
The Telos XL50 thermal imaging monocular is equipped with a sensor with a resolution of 1024 x 768 pixels (12 µm). The sensitivity of the sensor allows it to detect temperature differences below 40mK. The display is made using AMOLED HD technology with a resolution of 1024 x 768 pixels. The high-contrast display ensures better color reproduction, energy savings, fast response, and smooth images during observation, even in cold conditions. The refresh rate of 50 Hz allows for comfortable observation of moving objects. The thermal imaging monocular is equipped with 2.5–20x magnification and 12x digital zoom, and digital image stabilization ensures smooth and precise observation even at high zoom levels.
Smoothing filter, Picture in Picture mode
The smoothing filter function allows you to reduce digital distortion while maintaining a high level of sensitivity. The Picture in Picture mode allows you to enlarge the central part of the image in a specially displayed window. The additional window occupies only 10% of the total display area. For improved user comfort, the thermal imaging monocular is equipped with diopter adjustment in the range from -5 to +5.
8 image display modes
The thermal imaging monocular has eight image display modes for easy recognition and identification of objects under observation:
- White Hot - for object detection
- Black Hot - for object detection
- Hot Red - for object detection
- RedMonochrome - for long night observations
- Rainbow - for recognition and identification
- Ultramarine - for recognition and identification
- Violet - for long night observations
- Sepia - for long night observations
Wi-Fi module, 64 GB internal memory
The model features the function of saving photos or videos to the built-in 64 GB internal memory. Saved files can be transferred to a computer using a USB cable or directly to a phone or tablet using the integrated Wi-Fi module, which allows you to use, for example, a phone with the StreamVision 2 app as an external display or to remotely control the device.
Battery power supply
The thermal imaging monocular is powered by a replaceable lithium-ion battery LPS 7i with a capacity of 6400 mAh, which allows for up to 8 hours of operation. In addition, a quick charging system and USB-C power supply are included. The Display OFF energy saving mode allows you to turn off the display without turning off the thermal imager.
Set elements
- Pulsar XL50 thermal imaging monocular
- user manual in Polish
- USB/230V charger
- optical cleaning material
- neck strap
- lens cap
- cover
- USB-C to USB-C cable with USB-A adapter
- LPS 7i battery
Main features
- durable design
- IPX7 waterproof standard
- 2.5-20x magnification
- 12x digital zoom
- Amoled HD display
- smoothing filter
- Picture in Picture mode
- 8 image display modes
- Wi-Fi module
- 64 GB internal memory
- removable battery
Technical data
Sensor resolution: 1024 x 768 px, 12 µm
NETD: <40 mK
Display resolution: 1024 x 768 px
Image refresh rate: 50 Hz
Angular field of view: 14 deg.
Field of view m/100 m: 24.6 m
Magnification: 2.5-20x
Digital zoom: 8-12x
Internal memory: 64 GB
Maximum range: 2300 m
Dimensions: 238 x 72 x 62 mm
Waterproof rating: IPX7
Operating temperature: -25 to +50 deg. C
Dioptric correction of eyepiece: -5 to +5
Tripod mount: 1/4”
Power supply: rechargeable LPS 7i battery
Battery capacity: 6400 mAh
Weight: 680 g
Manufacturer: Pulsar, Lithuania
MILITARY is a premium dealer of Pulsar.
Pulsar is a European brand specializing in thermal imaging technology and digital day/night optics, owned by the Yukon Group and based in Lithuania. Its origins date back to 1991, when a group of enthusiasts began building their first devices at home. Today, the company employs over 1200 people and operates in more than 70 countries. All production takes place in Europe, and the brand has gained recognition for its innovative solutions, such as Dual-Purpose systems, which allow the device to be used as both a monocular and a rifle scope. The modern nature of the offer is emphasized by the Stream Vision 2 application, which allows wireless connection of devices to a phone via Wi-Fi, offering remote control, image transfer, and software updates. In 2005, the Yukon Group was the first to introduce digital night vision devices to the civilian market, marking in a new stage in the development of applied optoelectronics. In 2012, the Quantum model was unveiled – the first mass-produced thermal imaging monocular for civilians, and in 2019, the compact Axion XM30, capable of detecting a human silhouette from a distance of 1350 meters in complete darkness.
| Thermal imager type | Monocular |
|---|---|
| Display modes | 8 |
| Field of view | 24,6 m/ 100 m |
| Sensor resolution | 1024 x 768 |
| Screen resolution | 1024 x 768 |
| Waterproof class | IPX 7 |
| Power type | Interchangable accumulator |
| Accumulator/battery type | Li-Ion LPS 7i |
| Transport cover | Yes |
| Weight | 680 g |
| Objective lens diameter (mm) | 50 |
| Dimensions | 238 x 72 x 62 mm |
| Additional accessories included | Yes |
| Battery type | battery |
| Maximum detection depth | 2300 m |
| Built-in memory | Yes |
| EAN | 4779022926082 |
| Manufacturer code | 77516 |
| Brand | Pulsar |
| EAN |
