Pulsar Merger LRF XP35 Thermal Imaging Binoculars
Advanced thermal imaging binoculars capable of detecting objects from up to 1350 meters. Equipped with a high-precision laser rangefinder with a range of up to 1000 meters, provides a fixed optical magnification of 2x and a digital zoom of 2-16x.
Rugged construction, IPX7 standard
The body of the device is made of durable magnesium alloy, which provides high resistance to shock and mechanical damage. The binoculars meet the IPX7 waterproof standard, which guarantees protection against immersion in water up to a depth of 1 meter for up to 30 minutes. With an operating temperature range of -25 to +50°C, the device will perform well in all weather conditions.
Amoled HD display with a resolution of 1024 x 768 pixels
The binoculars are equipped with a thermal sensor with a resolution of 640 x 480 pixels with a pixel spacing of 17 μm. The sensitivity of the sensor allows it to capture temperature differences of less than 25 mK. The high-quality AMOLED HD display with a resolution of 1024 x 768 pixels provides smooth images, accurate color reproduction and fast response time, even at low temperatures. The 50 Hz image refresh rate allows you to comfortably track moving objects. The binoculars have a fixed optical magnification of 2x and a digital magnification of 2-16x.
Smoothing filter, Picture in Picture mode, laser rangefinder
A smoothing filter function reduces digital image distortion while maintaining high sensor sensitivity. The Picture in Picture mode allows the central part of the image to be magnified in an additional window that occupies only 10% of the display area, facilitating precise observation. Diopter adjustment from -5 to +5 allows the user to customize the image. The built-in laser rangefinder accurately measures distances up to 1000 meters with an accuracy of 1 meter.
8 image display modes
The binoculars have eight different display modes that make it easier to identify and observe objects in different conditions:
- White Hot - for object detection
- Black Hot - for object detection
- Hot Red - for object detection
- RedMonochrome - for long-term night observation
- Rainbow - for recognition and identification
- Ultramarine - for recognition and identification
- Violet - for long-term night observations
- Sepia - for long-term night observations
Wi-Fi module, 16 GB internal memory
The binoculars are equipped with a built-in internal memory of 16 GB, which allows you to save photos and videos. Files can be transferred to a computer via a USB cable or wirelessly to a smartphone or tablet using the integrated Wi-Fi module. The StreamVision 2 app allows you to use your phone as an external display or remote controller for the device.
Battery power supply
The model is powered by a replaceable 3200 mAh APS3 battery and a built-in 4000 mAh battery. Both power sources provide up to 9 hours of continuous operation. The USB-C port allows you to connect a powerbank to extend the device's runtime. The Display OFF function automatically turns off the display when the binoculars are not in use, further saving power.
Set elements
- APS3 rechargeable battery
- USB cable
- USB/230V charger
- optics cleaning material
- neck strap
- lens cap
- cover
- APS battery docking station
- 1/4” tripod adapter
- instruction manual in Polish
- warranty card with hologram
Main features
- rugged, waterproof design (IPX7)
- 2x optical magnification and 2-16x digital zoom
- built-in laser rangefinder
- 640 x 480 thermal sensor with NETD < 25 mK
- AMOLED HD display
- eight image display modes
- Picture in Picture function
- Wi-Fi module and 16 GB internal memory
- long working time thanks to two rechargeable batteries
- compact and lightweight design (830 g)
Application and activity examples
Uniformed services: With its precise laser rangefinder and long detection range, the Merger LRF XP35 is ideal for uniformed services operations. It enables monitoring of vast areas and detection of threats, even in difficult lighting conditions.
Outdoor: An excellent choice for nighttime wildlife observation enthusiasts. Allows discreet tracking of animals in their natural habitat, regardless of the weather. Rugged construction ensures reliability when used in demanding conditions.
Technical data
Thermal sensor resolution: 640 x 480, 17 μm
NETD: 25 mK
Display resolution: 1024 x 768
Image refresh rate: 50 Hz
Lens: 35 mm F/1.0
Field of view: 17.8 st, 31.3 m/100 m
Digital zoom: 2 - 16x
Optical zoom: 2x
Maximum detection range: 1350 m
Internal memory: 16 GB
Dimensions: 165 x 133 x 68 mm
Water resistance: IPX7
Operating temperature: -25 to +50 deg C
Power supply: built-in 4000 mAh battery, replaceable APS3 3200 mAh battery
Operating time: 9 h
Startup time: less than 3 s
Display: AMOLED HD
Dioptric correction: from -5 to +5
Weight: 830 g
Manufacturer: Pulsar, Lithuania
MILITARY is a premium dealer of Pulsar.
Pulsar is a European brand specializing in thermal imaging technology and digital day/night optics, owned by the Yukon Group and based in Lithuania. Its origins date back to 1991, when a group of enthusiasts began building their first devices at home. Today, the company employs over 1200 people and operates in more than 70 countries. All production takes place in Europe, and the brand has gained recognition for its innovative solutions, such as Dual-Purpose systems, which allow the device to be used as both a monocular and a rifle scope. The modern nature of the offer is emphasized by the Stream Vision 2 application, which allows wireless connection of devices to a phone via Wi-Fi, offering remote control, image transfer, and software updates. In 2005, the Yukon Group was the first to introduce digital night vision devices to the civilian market, marking in a new stage in the development of applied optoelectronics. In 2012, the Quantum model was unveiled – the first mass-produced thermal imaging monocular for civilians, and in 2019, the compact Axion XM30, capable of detecting a human silhouette from a distance of 1350 meters in complete darkness.
| Thermal imager type | Binoculars |
|---|---|
| Display modes | 8 |
| Reticle | No |
| Field of view | 31,3 m/ 100 m |
| Sensor resolution | 640 x 480 |
| Screen resolution | 1024 x 768 |
| Vehicle detection | 1350 m |
| Human detection | 1350 m |
| Waterproof class | IPX 7 |
| Power type | Built-in battery + replaceable battery |
| Transport cover | Yes |
| Weight | 830 g |
| Dimensions | 165 x 133 x 68 mm |
| Additional accessories included | Yes |
| Battery type | APS3 3200 mAh rechargeable battery |
| Maximum detection depth | 1350 m |
| Built-in memory | Yes |
| EAN | 4779022926099 |
| Manufacturer code | 77484 |
| Brand | Pulsar |
