Pulsar Axion Compact XG30 Thermal Imager
The Axion Compact XG30 thermal imaging monocular is designed for effective observation both during the day and at night. Equipped with an 8x digital zoom, it provides magnification from 2x to 16x, allowing you to accurately see objects up to 1,300 meters away. The stadiameter function assists in quickly determining the distance to a target of known dimensions.
Rugged housing and water resistance
The body of the device is made of magnesium alloy, which provides high resistance to shock and mechanical damage. The compact design and the seals used allow it to meet the IPX7 waterproof standard, which means resistance to immersion in water up to 1 meter deep for 30 minutes. The device performs well in extreme weather conditions, with a temperature range of -25°C to +40°C.
Advanced AMOLED display
The monocular uses a 12 μm technology sensor with a resolution of 640 x 480 pixels, which guarantees excellent image reproduction and captures temperature differences of less than 40 mK. The image is presented on an AMOLED display of the same resolution, characterized by high contrast, power saving and smooth operation at low temperatures. The 50 Hz refresh rate provides comfort when tracking moving objects.
The thermal imager is equipped with 8xdigital zoom, which provides magnification from 2x to 16x and allows you to see objects up to 1,300 meters away.
8 image display modes
The device allows the use of eight image display modes to facilitate the recognition and identification of observed objects:
- White Hot / Black Hot / Red Hot - for object detection
- RedMonochrome / Violet / Sepia - for long night observations
- Rainbow / Ultramarine - for recognition and identification
Stadiametric rangefinder
The Axion Compact XG30 is additionally equipped with a stadiametric rangefinder, which makes it easy to determine the approximate distance to a target of known size.
Wi-Fi module, 64 GB internal memory
The built-in 64GB memory allows you to store photos and videos. Files can be transferred to other devices using a USB cable or Wi-Fi module. The wireless function allows it to work with the StreamVision 2 app, which offers remote control and video display on a smartphone or tablet.
Rechargeable power supply
The thermal imager runs on a rechargeable 3200 mAh APS 3 lithium-ion battery, providing up to 7 hours of operation. It also integrates fast charging and the ability to power through a USB-C port. In addition, the Display OFF function allows you to temporarily blank the display to save power.
Set elements
- Pulsar Axion Compact XG30 thermal imager
- User manual in Polish
- USB/230V charger
- Material for cleaning optics
- Hand strap
- Lens cover
- Cover
- USB cable
- APS 3 rechargeable battery
Main features
- Durable design
- Compact size
- IPX7 waterproof standard
- 8x digital zoom
- Stadiametric rangefinder
- Amoled display
- 8 image display modes
- Wi-Fi module
- 64 GB internal memory
- Removable battery
Technical data
Sensor resolution: 640 x 480 px, 12 µm
NETD: <40 mK
Display resolution: 640 x 480 px
Image refresh rate: 50 Hz
Angular field of view: 14.6 deg.
Field of view m/100 m: 25.6 m
Digital zoom: 8x
Internal memory: 64 GB
Maximum range: 1300 m
Water resistance: IPX7
Operating temperature: -25 to +40 deg C
Dioptric correction of eyepiece: -5 to +5
Tripod mount: 1/4”
Power supply: rechargeable battery APS 3
Battery capacity: 3200 mAh
Dimensions: 144 x 41 x 69 mm
Weight: 240 g
Manufacturer: Pulsar, Lithuania
MILITARY is a premium dealer of Pulsar.
Pulsar is a European brand specializing in thermal imaging technology and digital day/night optics, owned by the Yukon Group and based in Lithuania. Its origins date back to 1991, when a group of enthusiasts began building their first devices at home. Today, the company employs over 1200 people and operates in more than 70 countries. All production takes place in Europe, and the brand has gained recognition for its innovative solutions, such as Dual-Purpose systems, which allow the device to be used as both a monocular and a rifle scope. The modern nature of the offer is emphasized by the Stream Vision 2 application, which allows wireless connection of devices to a phone via Wi-Fi, offering remote control, image transfer, and software updates. In 2005, the Yukon Group was the first to introduce digital night vision devices to the civilian market, marking in a new stage in the development of applied optoelectronics. In 2012, the Quantum model was unveiled – the first mass-produced thermal imaging monocular for civilians, and in 2019, the compact Axion XM30, capable of detecting a human silhouette from a distance of 1350 meters in complete darkness.
| Thermal imager type | Monocular |
|---|---|
| Display modes | 8 |
| Field of view | 25,6 m/ 100 m |
| Sensor resolution | 640 x 480 px |
| Transport cover | Yes |
| Dimensions | 144 x 41 x 69 mm |
| Additional accessories included | Yes |
| Screen resolution | 640 x 480 px |
| Weight | 240 g |
| Accumulator/battery type | Li-Ion APS 3 |
| Power type | Interchangable accumulator |
| Waterproof class | IPX 7 |
| Maximum detection depth | 1300 m |
| Built-in memory | Yes |
| EAN | 4779022926129 |
| Manufacturer code | 77508 |
| Brand | Pulsar |
| EAN |
