Hikvision Hikmicro Lynx LH15 3.0 Thermal Imager
Thermal imaging monocular is equipped with a 15 mm diameter lens. It allows magnification ranging from 2.2x to 17.6x (8x) and provides a wide field of view measuring 20.5 x 15.4 m at 100 meters, making it suitable for both close-range observation and mid-range object identification.
A model created for users in need of a fast and precise observation tool. The device is based on Hikmicro's latest technologies, characterized by high image quality in a compact form.
Compact and durable design, IP67 rating
The model's body is made of material resistant to mechanical damage and shocks, and with its solid construction and applied seals, the housing meets the IP67 standard, ensuring protection from dust, dirt, and immersion in water up to 1 meter deep for 30 minutes.
Shorter design and low weight facilitate transport – the thermal imager fits in a pocket or small bag. The non-slip surface and well-thought-out button layout allow easy one-handed operation, even with gloves.
sensitive VOx thermal sensor and AMOLED display
The model is equipped with a bright 15 mm diameter lens. The high-quality VOx thermal sensor with a resolution of 320 x 240 px and 12 µm pixel size ensures precise detail reproduction. Thermal sensitivity at the level of NETD <18 mK allows the detection of even minimal temperature differences, even in dense vegetation, poor visibility, or adverse weather conditions.
The image is displayed on a 1024 x 768 px resolution AMOLED screen. This screen is designed to minimize eye strain during prolonged observations, ensuring high comfort of use. Refresh rate at 50 Hz allows smooth observation of moving objects.
Modern Hikmicro technologies
The device incorporates modern Hikmicro technologies that enhance operational smoothness, improve image quality, and facilitate observation under varied terrain and lighting conditions:
- HSIS - Hikmicro Shutterless Image System - eliminates the need for traditional calibration, allowing uninterrupted and smooth observation without image "freezes." This helps maintain full focus on the target, regardless of conditions.
- Image Pro 3.0 - dynamic image processing system. Automatically adjusts contrast and sharpness, enhancing detail visibility in varying conditions.
- Zoom Pro - algorithm optimizing digital magnification. Maintains image detail and contrast at all zoom levels, enabling effective observation even at maximum zoom.
6 image display modes
The thermal imager allows the use of 6 image display modes that facilitate recognition and identification of observed objects:
- White Hot - the higher the temperature, the brighter the tone.
- Black Hot - the higher the temperature, the darker the tone.
- Red Hot - image like "White Hot" with red highlighting of the hottest elements.
- Fusion - from high temperature to low temperature, the image is colored from white, yellow, red, pink to purple.
- Red Monochrome - red monochrome palette, allows prolonged observation without eye strain.
- Green Monochrome - green monochrome palette, allows prolonged observation without eye strain.
Wi-Fi module and 64 GB internal memory
The model allows saving photos or videos on the built-in 64 GB internal memory. Thanks to the Wi-Fi 2.4/5 GHz module, the thermal imager can connect to the Hikmicro Sight app on a smartphone, enabling remote viewing, storage, and sharing of images.
battery power, short startup time
The device is powered by a replaceable Li-ion 18650 battery, providing up to 5.5 hours of continuous operation. The built-in USB-C port allows convenient charging of the cell from a car charger, computer, or power bank.
A short startup time of only 2 seconds allows nearly instant observation initiation. The auto screen-off function automatically dims the screen, saving power and extending operating time.
set elements
- thermal imager
- 2x 18650 battery
- USB-C cable
- battery charger
- user manual
main features
- thermal sensor with 320 x 240 px resolution
- magnification 2.2x-17.6x (8x)
- 15 mm diameter lens (f1.0)
- AMOLED screen with 1024 x 768 px resolution
- sensitivity NETD <18 mK
- field of view 20.5 x 15.4 m at 100 m
- detection range 750 meters
- refresh rate 50Hz
- quick start - operational readiness in 2 seconds
- Image Pro 3.0 and Zoom Pro algorithms
- modern HSIS technology
- 6 color palettes
- built-in 64 GB memory
- shock-resistant housing
- IP67 rating
- battery power
- auto screen-off function
- Wi-Fi 2.4/5 GHz connectivity
- operating temperature from -30 to +45 deg. C.
MILITARY is a premium dealer of Hikmicro.
Hikmicro belongs to the dynamically developing Hikvision group and specializes in thermal imaging technologies and optoelectronics. The brand's product range includes thermal imaging cameras, monoculars, and diagnostic devices used in industry, property protection, rescue operations, and nature observation, among other areas. Hikmicro solutions are used in over 100 countries around the world. Thanks to advanced technologies such as DDE, 3D DNR, and AGC, they provide high image quality even in adverse weather conditions and low light. The brand draws on Hikvision's technological resources while developing its own product lines for both professional and civilian users. Hikmicro's image analysis system, which uses artificial intelligence algorithms, enables faster object detection and more precise detail recognition. Thanks to its innovative approach, the company has quickly gained a strong position in the thermal imaging technology market.
| Optics ready | No |
|---|---|
| Thermal imager type | Monocular |
| Display modes | 6 |
| Reticle | No |
| Field of view | 750 m/ 100 m |
| Sensor resolution | 320 x 240 px |
| Transport cover | No |
| Main color | Black |
| Dimensions | 156,3 x 53,6 x 49,5 mm |
| Additional accessories included | Yes |
| Screen resolution | 1024 x 768 px |
| Objective lens diameter (mm) | 15 |
| Weight | 296,5 g |
| Accumulator/battery type | 1x Li-Ion 18650 |
| Power type | Interchangable accumulator |
| Waterproof class | IP 67 |
| Maximum detection depth | 750 m |
| Built-in memory | Yes |
| EAN | 6974004648893 |
| Manufacturer code | 19290 |
| Brand | Hikvision |
