Hikvision Hikmicro Lynx LE10 3.0 Thermal Imager
Thermal monocular with a 9.7 mm diameter lens. It allows for magnification ranging from 1.4x to 11.2x (8x) and offers a wide field of view of 31.7 x 23.8 m at 100 meters, making it suitable for observing the close surroundings and identifying objects at medium distances.
The model is designed for users who require a fast and precise observation tool. It utilizes the latest Hikmicro technologies and features high image quality in a compact form.
Compact and durable design, IP67 protection rating
The body of this model is made from material resistant to mechanical damage and shocks. The compact design and applied seals ensure that the housing meets the IP67 protection rating, protecting against dust, dirt, and immersion in water up to 1 meter for 30 minutes.
The compact design and lightweight make transportation easy - the device fits easily in a pocket or small bag. The anti-slip external surface and well-thought-out button layout allow for easy one-handed operation, even with gloves.
Sensitive thermal sensor and AMOLED display
The model features a bright 9.7 mm diameter lens. A high-quality thermal sensor with a resolution of 256 x 192 px and a pixel size of 12 µm ensures precise detail reproduction. Thermal sensitivity at the level of NETD <20 mK allows detection of even minimal temperature differences in dense vegetation, under poor visibility, or adverse weather conditions.
The image is displayed on an AMOLED screen with a resolution of 1024 x 768 px. The display is designed to minimize eye strain during prolonged observation, translating to high user comfort. A refresh rate of 50 Hz enables convenient observation of moving objects.
Advanced Hikmicro technologies
The device utilizes modern Hikmicro technologies, which enhance operational smoothness, improve image quality, and support observation in various terrain and lighting conditions:
- HSIS - Hikmicro Shutterless Image System - eliminates the need for traditional calibration, enabling continuous and smooth observation without image "freezing". This facilitates focusing on the target, regardless of prevailing conditions.
- Image Pro 3.0 - a dynamic image processing system that automatically adjusts contrast and sharpness, improving detail visibility in changing conditions.
- Zoom Pro - an algorithm optimizing digital zoom. It maintains image detail and contrast at all zoom levels, allowing effective observation even at maximum magnification.
6 image display modes
The thermal imager allows using 6 image display modes that facilitate the recognition and identification of observed objects:
- White Hot - the higher the temperature, the brighter the tone.
- Black Hot - the higher the temperature, the darker the tone.
- Red Hot - image like "White Hot" with red highlighting of the warmest elements.
- Fusion - colorful image from white, yellow, red, pink to purple, transitioning from high to low temperature.
- Red Monochrome - red monochrome palette, allowing long-term observation without eye strain.
- Green Monochrome - green monochrome palette, also conducive to long-term observation without eye strain.
Wi-Fi module and 64 GB internal memory
The model incorporates a function that allows saving photos or videos on the built-in 64 GB internal memory. The Wi-Fi 2.4/5 GHz module enables connecting the thermal imager with the Hikmicro Sight app on a smartphone, allowing remote viewing, saving, and sharing images.
Battery power, short startup time
The device is powered by a replaceable Li-ion 18650 battery, allowing for up to 4.5 hours of continuous operation. An integrated USB-C port enables charging from various sources, such as a car charger, computer, or power bank.
A short startup time of only 2 seconds allows for almost immediate observation. The auto screen-off function automatically dims the screen, conserving energy and prolonging operating time.
Set elements
- Thermal imager
- 2x 18650 battery
- USB-C cable
- Battery charger
- User manual
Main features
- Thermal sensor with a resolution of 256 x 192 px
- Magnification 1.4x-11.2x (8x)
- 9.7 mm diameter lens (f1.0)
- AMOLED screen with a resolution of 1024 x 768 px
- NETD sensitivity <20 mK
- Field of view 31.7 x 23.8 m at 100 m
- Detection range 500 meters
- Refresh rate 50Hz
- Quick start - ready to work in 2 seconds
- Image Pro 3.0 and Zoom Pro algorithms
- Modern HSIS technology
- 6 color palettes
- Built-in 64 GB memory
- Shock-resistant housing
- IP67 protection rating
- Battery-powered
- Auto screen-off function
- Wi-Fi 2.4/5 GHz connectivity
MILITARY is a premium dealer of Hikmicro.
Hikmicro belongs to the dynamically developing Hikvision group and specializes in thermal imaging technologies and optoelectronics. The brand's product range includes thermal imaging cameras, monoculars, and diagnostic devices used in industry, property protection, rescue operations, and nature observation, among other areas. Hikmicro solutions are used in over 100 countries around the world. Thanks to advanced technologies such as DDE, 3D DNR, and AGC, they provide high image quality even in adverse weather conditions and low light. The brand draws on Hikvision's technological resources while developing its own product lines for both professional and civilian users. Hikmicro's image analysis system, which uses artificial intelligence algorithms, enables faster object detection and more precise detail recognition. Thanks to its innovative approach, the company has quickly gained a strong position in the thermal imaging technology market.
| Optics ready | No |
|---|---|
| Thermal imager type | Monocular |
| Display modes | 6 |
| Reticle | No |
| Field of view | 31,7 x 23,8 m/ 100 m |
| Sensor resolution | 256 x 192 px |
| Transport cover | No |
| Main color | Black |
| Dimensions | 152,4 x 53,6 x 49,5 mm |
| Additional accessories included | Yes |
| Screen resolution | 1024 x 768 px |
| Objective lens diameter (mm) | 9,7 |
| Weight | 291,5 g |
| Accumulator/battery type | 1x Li-Ion 18650 |
| Power type | Interchangable accumulator |
| Waterproof class | IP 67 |
| Maximum detection depth | 500 m |
| Built-in memory | Yes |
| EAN | 6974004648879 |
| Manufacturer code | 19292 |
| Brand | Hikvision |
